Product description
Technical Specification:
Traverse X: 1,100mm
Traverse Y: 610mm
Traverse Z: 560mm
Table Size: 1,250 x 600mm
Maximum table load 1,000kg
Spindle nose line to table surface 80-640mm
Maximum cutting feed rate X/Y/Z 10/10/10m/min
Rapid traverse rates X/Y 30m/min
Rapid traverse rates Z 30m/min
Speed range 20-10,000rpm
Spindle motor max output See information overleaf
Spindle taper BT40 or (CAT flange opt)
Twin arm type auto tool changer 24 station
Maximum tool diameter 75mm
Maximum tool diameter 160mm adjacent pockets empty
Maximum tool length 250mm
Maximum tool weight 7kg
Tool change time 2.2 seconds
Machine weight 6,600kg
